参照 |
部品名 |
|
モデル部品 |
|
VENTURI |
|
|
 |
REBUILD KIT |
|
|
 |
GASKET & DIAPHRAGM KIT |
|
|
| 1 |
Nozzle Ass'y, Check Valve |
|
|
| 2 |
Plug |
|
|
| 3 |
Metering lever |
|
|
| 4 |
Pin |
|
|
| 5 |
Inlet needle |
|
|
| 6 |
Metering spring |
|
|
| 7 |
Pan head screw |
|
|
| 8 |
Metering gasket |
|
|
| 9 |
Metering diaphragm assy |
|
|
| 10 |
Pump body assy |
|
|
| 11 |
STRAINER |
|
|
| 12 |
DIAPHRAGM PUMP |
|
|
| 13 |
GASKET PUMP |
|
|
| 14 |
PUMP COVER ASS'Y |
|
|
| 15 |
SCREW |
|
|
| 16 |
SHAFT ASS'Y THROTTLE |
|
|
| 17 |
Throttle lever |
|
|
| 18 |
Binding head screw |
|
|
| 19 |
SHAFT ASS'Y AIR HEAD |
|
|
| 20 |
SHAFT ASS'Y CHOKE |
|
|
| 21 |
LEVER CHOKE |
|
|
| 22 |
LEVER CHOKE ASS'Y |
|
|
| 23 |
E-ring |
|
|
| 24 |
Idle speed screw |
|
|
| 25 |
VALVE CHOKE |
|
|
| 26 |
Valve screw |
|
|
| 27 |
Throttle valve |
|
|
| 28 |
VALVE THROTTLE |
|
|
| 29 |
Valve screw |
|
|
| 30 |
High speed screw |
|
|
| 31 |
Low speed screw |
|
|
| 32 |
Friction piece |
|
|
| 33 |
SPRING THROTTLE RETURN |
|
|
| 34 |
SPRING AIR THROTTLE RETURN |
|
|
| 35 |
COLLAR |
|
|
| 36 |
SPRING CHOKE RETURN |
|
|
| 37 |
BOOT |
|
|
| 38 |
SCREW |
|
|
| 39 |
Plug, Welch |
|
|
